3 Series Compact Tractors
SAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm
3025D / 3025D Compact Tractorinfo
3025D / 3025D Compact Tractor Details
- Standard 4WD for Maximum Traction
- Heavy duty drive train with a gear drive transmission 8F/8R
- On-board diagnostics including Service Advisor
For pricing and additional discounts, see your local John Deere Dealer.
Key Specs
- Engine power (gross)SAE J1995 rated power: 18.2 kW
24.4 hp
24.7 PS at 2400 rpm - Power take-off (PTO) power15.4 kW
20.7 hp - Steering hydraulics14.4 L/min
3.8 gpm - Implement hydraulics19.2 L/min
5.1 gpm - Hitch typeCategory 1
- Lift capacity, 24-in. behind link arms944 kg
2081.2 lb - Standard transmission; forward/reverse8F/8R synchromesh shuttle shift gear transmission
- Cruise controlNo
- Approximate shipping weight (open-station; cab)Open operator station (OOS): 1260 kg
2778 lb
Cab: Not applicable - Wheelbase1574 mm
62 in.
Engine
- ManufacturerYanmar®
- Engine model3TNV88F-EPJPT
- Engine power (gross)SAE J1995 rated power: 18.2 kW
24.4 hp
24.7 PS at 2400 rpm - Power take-off (PTO) power15.4 kW
20.7 hp - Rated engine speed2400 rpm
- Injection pump typeDirect injection
- AspirationNatural
- Emissions complianceFinal Tier 4
- Cylinders/displacement3 / 1.64 L
3 / 100.2 cu in. - Number of cylindersThree
- Cylinder linersCast-in-block
- Bore and stroke88 x 90 mm
3.46 x 3.54 in. - Compression ratio19.1:1
- LubricationPressurized
- Cooling systemLiquid
- Air cleanerDual element
- Engine torque at rated speed72.4 Nm
53.4 lb-ft - Fuel tank capacity36.7 L
9.7 U.S. gal.
Electrical
- Battery size600 CCA
- Alternator (12-V)55 amp
- Starter size1.4 kW
1.9 hp
Fuel system
- TypeDirect injection
Transmission
- Standard transmission; forward/reverse8F/8R synchromesh shuttle shift gear transmission
- Left-hand reverserYes
- Transmission gear rangesFour gears and two ranges
- Final driveSpur gear
- BrakesWet disk
- SteeringPower steering
- Axle capacityFront
880 kg
1940 lb
Rear
1600 kg
3527 lb - CreeperNo
- Cruise controlNo
- Differential lockYes
Hydraulics
- TypeOpen center
- Pump rated outputSteering
14.4 L/min
3.8 gpm
Implement
19.2 L/min
5.1 gpm
33.6 L/min
8.9 gpm - Pump typeSingle gear
- Maximum operating pressure172 bar
2495 psi - Draft control sensingPosition control
- Remote control valves availableUp to two (optional)
3-point hitch
- TypeCategory 1
- Lift capacity, 24-in. behind link arms944 kg
2081.2 lb
Power take-off (PTO)
- StandardAt 2400 rpm: 540 rpm
- ControlMechanical
- ClutchTransmission
- Brake (for mid and rear PTO)Wet disk
Fluid capacities
- Crankcase with filter4.5 L
4.8 gal. - Transmission and hydraulic system33 L
34.8 qt
Final drive
- TypeSpur gear
Operator station
- Rollover protective structureType
Foldable
ASABE S478 - Platform - flat/straddleStraddle
- Gear shift location - console/floorRight-hand side
Cab
Dimensions
- Wheelbase1574 mm
62 in. - Front axle clearanceMinimum: 331 mm
13 in.
Maximum: 353 mm
13.9 in. - Turning radius with brakes1.63 m
5.3 ft - Approximate shipping weight (open-station; cab)OOS: 1260 kg
2778 lb
Cab: Not applicable
Tires
- FrontR1 Bar: 7-14
R3 Turf: 27x8.5-15
R4 Industrial: 25x8.5-14 - RearR1 Bar: 11.2-24
R3 Turf: 41x14-20
R4 Industrial: 15-19.5
Miscellaneous
- ToolboxYes
- Tilt steering wheelNo
- 12-V OutletNo
