3 Series Compact TractorsSAE J1995 rated power: 18.2 kW 24.4 hp 24.7 PS at 2400 rpm
3025E / 3025E Compact Utility Tractorinfo
3025E / 3025E Compact Utility Tractor Details
- Standard four-wheel drive (4WD) for maximum traction
 - Tightest turning radius in its horsepower class
 - Hydro transmission with Twin Touch™ pedals for ease of use

For pricing and additional discounts, see your local John Deere Dealer.
Key Specs
- Engine power (gross)SAE J1995 rated power: 18.2 kW
24.4 hp
24.7 PS at 2400 rpm - Power take-off (PTO) power13 kW
17.4 hp - Steering hydraulics15 L/min
4 gpm - Implement hydraulics20.2 L/min
5.3 gpm - Hitch typeCategory 1
 - Lift capacity, 24-in. behind link arms615 kg
1356 lb - Standard transmission; forward/reverseHydrostatic transmission (HST)
 - Cruise controlOptional
 - Approximate shipping weight (open-station; cab)Open operator station (OOS):  1181 kg
2603 lb
Cab: Not applicable - Wheelbase1593 mm
62.7 in.
Engine
- FamilyEYDXL1.64NDA
FYDXL1.64NDA
GYDXL1.64NDA - ManufacturerYanmar
 - Engine model3TNV88F-EPJT2
 - Engine power (gross)SAE J1995 rated power: 18.2 kW
24.4 hp
24.7 PS at 2400 rpm - Power take-off (PTO) power13 kW
17.4 hp - Rated engine speed2400 rpm
 - TypeDiesel
 - Injection pump typeDirect injection
 - AspirationNatural
 - Emissions complianceFinal Tier 4
 - Cylinders/displacement3 / 1.64 L
3 / 100.2 cu in. - Number of cylindersThree
 - Cylinder linersCast-in-block
 - Bore and stroke88 x 90 mm
3.46 x 3.54 in. - Compression ratio19.1:1
 - LubricationPressurized
 - Cooling systemWater pump
 - Air cleanerDual element
 - Engine torque at rated speed72.4 Nm
53.4 lb-ft - Fuel tank capacity28.5 L
7.5 U.S. gal.
Electrical
- Battery size500 CCA
 - Alternator (12-V)55 amp
 - Starter size1.4 kW
1.9 hp
Fuel system
- TypeDirect injection

Transmission
- Standard transmission; forward/reverseHydrostatic transmission (HST)
 - Left-hand reverserNo
 - Final driveSpur gear
 - BrakesWet disk
 - SteeringPower steering
 - Axle capacityFront
880 kg
1940 lb
Rear
1200 kg
2645 lb - CreeperNo
 - Cruise controlOptional
 - Differential lockYes

Hydraulics
- TypeOpen center
 - Pump rated outputSteering
15 L/min
4 gpm
Implement
20.2 L/min
5.3 gpm
35.2 L/min
9.3 gpm - Pump typeDual gear
 - Maximum operating pressure172 bar
2495 psi - Draft control sensingPosition control
 - Remote control valves availableUp to two (optional)

3-point hitch
- TypeCategory 1
 - Lift capacity, 24-in. behind link arms615 kg
1356 lb
Power take-off (PTO)
- StandardRear - 540 rpm
 - ControlIndependent
 - ClutchWet disk
 - Brake (for mid and rear PTO)Wet disk

Fluid capacities
- Crankcase with filter4.5 L
4.8 gal. - Transmission and hydraulic system20.8 L
22 qt
Final drive
- TypeSpur gear

Operator station
- Rollover protective structureType
Foldable - Platform - flat/straddleStraddle
 - Gear shift location - console/floorLeft-hand side

Cab
Dimensions
- Wheelbase1593 mm
62.7 in. - Front axle clearanceMinimum: 299 mm
11.8 in.
Maximum: 333 mm
13.1 in. - Turning radius without brakes2.9 m
9.4 ft - Approximate shipping weight (open-station; cab)OOS:  1181 kg
2603 lb
Cab: Not applicable
Tires
- FrontR1 Bar: 7-14
R3 Turf: 27x8.5-15
R4 Industrial: 25x8.5-14
R4 Industrial: 27x8.5-15 - RearR1 Bar: 11.2-24
R3 Turf: 41x14-20
R4 Industrial: 15-19.5
R4 Industrial: 43x16-20
Miscellaneous
