2 Series Compact TractorsSAE J1995 rated power: 22.9 kW 30.7 hp 31.2 PS at 2500 rpm
2032R / 2032R Compact Tractor with 220R Loaderinfo
2032R / 2032R Compact Tractor with 220R Loader Details
- Standard LED headlights and fender lights
- Comfortable, marine-grade seat stays in top condition
- Larger, heavier frame for added stability
- Up to 72" AutoConnect™ mid-mower deck can be installed or removed in under 5 minutes
For pricing and additional discounts, see your local John Deere Dealer.
Key Specs
- Engine power (gross)SAE J1995 rated power: 22.9 kW
30.7 hp
31.2 PS at 2500 rpm - Power take-off (PTO) power18 kW
24.2 hp - Steering hydraulics15 L/min
4 gpm - Implement hydraulics20.2 L/min
5.3 gpm - Hitch typeCategory 1
- Lift capacity, 24-in. behind link arms615 kg
1356 lb - Standard transmission; forward/reverseHydrostatic transmission (HST)
- Cruise controlStandard
- Approximate shipping weight (open-station; cab)Open station: 1306 kg
2879 lb
Cab: Not applicable - Wheelbase1723 mm
67.8 in.
Engine
- ManufacturerYanmar®
- Engine model3TNV88C-NJT2
- Engine power (gross)SAE J1995 rated power: 22.9 kW
30.7 hp
31.2 PS at 2500 rpm - Power take-off (PTO) power18 kW
24.2 hp - Rated engine speed2500 rpm
- TypeDirect Injection
- Injection pump typeDirect Injection
- AspirationNatural
- Emissions complianceFinal Tier 4
- Cylinders/displacementThree cylinders: 1.642 L
100.2 cu in. - Number of cylindersThree
- Cylinder linersCast-in-block
- Bore and stroke88x90 mm
3.46x3.54 in. - Compression ratio19.1:1
- LubricationPressurized
- Cooling systemWater pump
- Air cleanerDual element
- Engine torque at rated speed87.5 Nm
64.5 lb-ft - Fuel tank capacity32 L
8.5 U.S. gal.
Electrical
- Battery size500 CCA
- Alternator (12-V)85 amp
- Starter size1.4 kW
1.9 hp
Fuel system
- TypeDirect Injection
Transmission
- Standard transmission; forward/reverseHydrostatic transmission (HST)
- Final driveSpur gear
- BrakesWet disc
- SteeringPower steering
- Axle capacityFront
880 kg
1940 lb
Rear
1800 kg
3968 lb - CreeperNo
- Cruise controlStandard
- Differential lockYes
Hydraulics
- TypeOpen center
- Pump rated outputSteering
15 L/min
4 gpm
Implement
20.2 L/min
5.3 gpm
35.2 L/min
9.3 gpm - Pump typeDual gear
- Maximum operating pressure172 bar
2495 psi - Draft control sensingPosition control
- Remote control valves availableUp to three
3-point hitch
- TypeCategory 1
- Lift capacity, 24-in. behind link arms615 kg
1356 lb
Power take-off (PTO)
- StandardRear: 543 rpm
Mid: 1998 rpm - ControlIndependent
- ClutchWet disc
- Brake (for mid and rear PTO)Wet disc
Fluid capacities
- Crankcase with filter4.5 L
4.8 gal.
Final drive
- TypeSpur Gear
- Differential lockYes
Operator station
- Rollover protective structureType
Foldable
ASABE S478 - Platform - flat/straddleSemi-flat
Cab
Dimensions
- Wheelbase1723 mm
67.8 in. - Turning radius with brakes2.46 m
8.07 ft - Approximate shipping weight (open-station; cab)Open station: 1306 kg
2879 lb
Cab: Not applicable
Tires
- FrontR1 Ag 7.00-12
R3 Turf 23x8.50-14
R4 Industrial 23x8.50-14
R3 Turf Radial 200/60 R15 - RearR1 Ag 12.4-16
R3 Turf 14-17.5
R4 Industrial 14-17.5
R3 Turf Radial 300/70 R20
Miscellaneous
- ToolboxYes
- Tilt steering wheelYes
- 12-V OutletYes
Additional information
