Total: $22,795.00
MSRP: $28,898.50
**Price subject to change. Contact Meade Tractor for complete details.
2 Series Compact Tractors
$23,795.00SAE J1995 rated power: 17.8 kW 23.9 hp 24.2 PS at 3200 rpm
2025R / 2025R Compact Tractor w/120R Loaderinfo
2025R / 2025R Compact Tractor w/120R Loader Details
- Standard LED headlights and fender lights
- Hydro transmission with TwinTouch™ pedals for ease of use
- AutoConnect™ mid-mower deck can be installed or removed in less than 5 minutes
For pricing and additional discounts, see your local John Deere Dealer.
Key Specs
- Engine power (gross)SAE J1995 rated power: 17.8 kW
23.9 hp
24.2 PS at 3200 rpm - Power take-off (PTO) power13.6 kW
18.2 hp - Steering hydraulics13.4 L/min
3.5 gpm - Implement hydraulics13.4 L/min
3.5 gpm - Hitch typeLimited Category 1
- Lift capacity, 24-in. behind link arms415 kg
915 lb - Standard transmission; forward/reverseHydrostatic - two range
- Cruise controlStandard
- Approximate shipping weight (open-station; cab)Open station: 849 kg
1872 lb
Cab: 1085 kg
2392 lb - Wheelbase1600 mm
63 in.
Engine
- ManufacturerYanmar®
- Engine model3TNV80F-NCJT
- Engine power (gross)SAE J1995 rated power: 17.8 kW
23.9 hp
24.2 PS at 3200 rpm - Power take-off (PTO) power13.6 kW
18.2 hp - Rated engine speed3200 rpm
- TypeDiesel
- Injection pump typeIndirect injection
- AspirationNatural
- Emissions complianceFinal Tier 4
- Cylinders/displacementThree cylinders: 1.267 L
77 cu in. - Number of cylindersThree
- Cylinder linersCast-in-block
- Bore and stroke80 x 84 mm
3.2 x 3.3 in. - Compression ratio23.1:01
- LubricationPressurized
- Cooling systemWater pump
- Air cleanerDual element
- Engine torque at rated speed53.1 Nm
39.1 lb-ft - Fuel tank capacity20.4 L
5.39 gal.
Electrical
- Battery size500 CCA
- Alternator (12-V)40 amp
- Starter size1.2 kW
1.6 hp
Fuel system
- TypeIndirect injection
Transmission
- Standard transmission; forward/reverseHydrostatic - two range
- Left-hand reverserNo
- Final driveSpur gear
- BrakesWet disc
- SteeringPower steering
- Axle capacityFront
612 kg
1349 lb
Rear
1100 kg
2425 lb - CreeperNo
- Cruise controlStandard
- Differential lockYes
Hydraulics
- TypeOpen center
- Pump rated outputSteering
13.25 L/min
3.5 gpm
Implement
13.25 L/min
3.5 gpm
26.5 L/min
7.0 gpm - Pump typeGear
- Maximum operating pressure137 bar
1987 psi - Draft control sensingPosition control
- Remote control valves availableTwo
3-point hitch
- TypeLimited Category 1
- Lift capacity, 24-in. behind link arms415 kg
915 lb
Power take-off (PTO)
- StandardRear - 540 rpm
Mid - 2100 rpm - ControlIndependent
- ClutchWet disk
- Brake (for mid and rear PTO)Wet disk
Fluid capacities
- Crankcase with filter2.7 L
2.9 gal.
Final drive
- TypeSpur gear
- Differential lockYes
Operator station
- Rollover protective structureType
Foldable
OSHA, SAE, ASAE - Platform - flat/straddleThree-piece semi flat
- Gear shift location - console/floorLeft-hand side
Cab
Dimensions
- Wheelbase1600 mm
63 in. - Turning radius without brakesOutside front tire: 2.51 m
8.2 ft - Limited slip differentialNo
- Approximate shipping weight (open-station; cab)Open station: 849 kg
1872 lb
Cab: 1085 kg
2392 lb
Tires
- FrontR3 Turf: 23x8.50-12
R3 Radial: 220/55-R12
R4 Industrial: 23x8.50-12 - RearR3 Turf: 12-16.5
R3 Radial: 280/70 R16
R4 Industrial: 12-16.5
Miscellaneous
- ToolboxYes
- Tilt steering wheelYes
- 12-V OutletYes
Additional information
